SPECIFICATIONS AND CHARACTERISTICS:
|
● Volts & Cover Color - Gray standard for 120VAC - Blue standard for 120-277VAC (105-305VAC) 50/60Hz ● Turn-ON Light Level: 10-16 Lux ● Turn ON/OFF Ratio: 1:1.5 to 4 ● Time Delay: 3-15 sec ● Operating Temperature: -40℃ to +70℃ ● Relay: 30A ● MOV Surge Protection: 90/190J/380J(10/1000us) ● Energy Consumption: Less than 1Watt（120V<0.5W） ● Electrical Life: >5000 cycles ● Sensor Type: Silicon Photocell ● Housing: UV stabilized PC ● Failure Mode: Fail OFF ● Size: 80mm,74mm (suitable for North America market) |
● ANSI C136.10 & UL773 Standard ● UL Listed. Reference No.: E178670 ● Rated Load:
|
● Volts & Cover Color
- Gray standard for 120VAC
- Blue standard for 120-277VAC (105-305VAC) 50/60Hz
● Turn-ON Light Level: 10-16 Lux
● Turn ON/OFF Ratio: 1:1.5 to 4
● Time Delay: 3-15 sec
● Operating Temperature: -40℃ to +70℃
● Relay: 30A
● MOV Surge Protection: 90/190J/380J(10/1000us)
● Energy Consumption: Less than 1Watt（120V<0.5W）
● Electrical Life: >5000 cycles
● Sensor Type: Silicon Photocell
● Housing: UV stabilized PC
● Failure Mode: Fail OFF
● Size: 80mm,74mm (suitable for North America market)
● ANSI C136.10 & UL773 Standard
● UL Listed. Reference No.: E178670
● Rated Load:
- Gray standard for 120VAC
- Blue standard for 120-277VAC (105-305VAC) 50/60Hz
● Turn-ON Light Level: 10-16 Lux
● Turn ON/OFF Ratio: 1:1.5 to 4
● Time Delay: 3-15 sec
● Operating Temperature: -40℃ to +70℃
● Relay: 30A
● MOV Surge Protection: 90/190J/380J(10/1000us)
● Energy Consumption: Less than 1Watt（120V<0.5W）
● Electrical Life: >5000 cycles
● Sensor Type: Silicon Photocell
● Housing: UV stabilized PC
● Failure Mode: Fail OFF
● Size: 80mm,74mm (suitable for North America market)
● ANSI C136.10 & UL773 Standard
● UL Listed. Reference No.: E178670
● Rated Load:
|
Code |
Specification |
|
10DG1 |
120V/1000W |
|
10DG3 |
120-277V/1800VA |
