● Volts & Cover Color – 50/60Hz - Gray standard for 120Vac - Maroon standard for 220Vac ● Rated Voltage: 120VAC, 220VAC ● Turn-On Light Level: 10-16 Lux, adjustable at customer’s request ● Turn-Off Light Level: <65 Lux, adjustable at customer’s request ● Turn-On Time Delay: 30-180sec ● Turn-Off Time Delay: 30-180sec ● Operating Temperature: -40℃ to +70℃ ● Energy Consumption: Less than 1Watt (120V<0.7W) ● Load Switching Capability: 5,000 operations at ANSI specified load test levels ● Sensor Type: CDS ● Housing: UV stabilized PC ● Failure Mode: Fail ON ● Size: 74mm (suitable for North America market), 74mm (Window) |
● UL Listed. Reference No.: E178670 ● ANSI C136.10 & UL773 Standard ● Rated Load:
Notes:The thermal type photocontrol may not work properly if the supplied power is lower than 85% of rated voltage. |
● Volts & Cover Color – 50/60Hz
- Gray standard for 120Vac
- Maroon standard for 220Vac
● Rated Voltage: 120VAC, 220VAC
● Turn-On Light Level: 10-16 Lux, adjustable at customer’s request
● Turn-Off Light Level: <65 Lux, adjustable at customer’s request
● Turn-On Time Delay: 30-180sec
● Turn-Off Time Delay: 30-180sec
● Operating Temperature: -40℃ to +70℃
● Energy Consumption: Less than 1Watt (120V<0.7W)
● Load Switching Capability: 5,000 operations at ANSI specified load test levels
● Sensor Type: CDS
● Housing: UV stabilized PC
● Failure Mode: Fail ON
● Size: 74mm (suitable for North America market), 74mm (Window)
● UL Listed. Reference No.: E178670
● ANSI C136.10 & UL773 Standard
● Rated Load:| Code | Specification |
| 10H1 | 120V/1000W/1800VA |
| 10H2 | 220V/2000W/1800VA |
| 10L1 | 120V/1000W/1200VA |
| 10L2 | 220V/1000W/1200VA |
Notes:The thermal type photocontrol may not work properly if the supplied power is lower than 85% of rated voltage.
